HWL600R Solar Pile Driver Pile Driver
SKU: HWL600R
HWL600R Solar Pile Driver Pile Driver — Operating weight 7464 kg, Impact energy 1800 J, Engine brand Yuchai, Rated power 85 kW. Supplied by Shandong Hengwang Group Co., Ltd.
تفاصيل المنتج
Technical Specifications
- Operating weight: 7464 kg
- Impact energy: 1800 J
- Engine brand: Yuchai
- Rated power: 85 kW
- Max torque / speed: 375/1850 N·m/rpm
- Fuel tank capacity: 150 L
- Rated displacement: 105 ml/r
- Working pressure: 19 MPa
- Rated flow: 230 L/min
- Hydraulic tank capacity: 230 L
- Hydraulic hammer model: 100 Series
- Max impact frequency of hydraulic hammer: 800 Bpm
- Drill steel diameter: 100 mm
- Max pile rod length: 6 m
- Gradeability: 25 °
- Transport dimensions: 7760×2375×1980 mm
- Tail swing radius: 2030 mm
- Min ground clearance: 290 mm
Product Overview
The HWL600R Solar Pile Driver Pile Driver is supplied by Shandong Hengwang Group Co., Ltd, listed under Drilling and Piling Equipment / Pile Drivers. Key specifications: Operating weight 7464 kg; Impact energy 1800 J; Engine brand Yuchai; Rated power 85 kW; Max torque / speed 375/1850 N·m/rpm; Fuel tank capacity 150 L.
Key Features
- Operating weight: 7464 kg
- Impact energy: 1800 J
- Engine brand: Yuchai
- Rated power: 85 kW
- Max torque / speed: 375/1850 N·m/rpm
Applications
- Pile foundation construction at solar power stations
- Farm water conservancy and fence post installation
- Municipal and road guardrail post installation
- Micro-pile construction for building foundations
- Piling on slopes, hills and other complex terrain
الفئات
Drilling and Piling Equipment / Pile Drivers
تفاصيل المنتج
مرجع المنتج
- Product name: HWL600R Solar Pile Driver Pile Driver
- SKU / Model code: HWL600R
- الفئات: Drilling and Piling Equipment / Pile Drivers
- المورد: MachEquipPro
